10mm 10mm2 8mm2 Sistema de Energia Térmica Solar DC PV de Cobre Fios Cabo
10mm 10mm2 8mm2 Sistema de Energia Térmica Solar DC PV de Cobre Fios Cabo image
Get Latest Price Request a quote
You May Like
Product Details
Product Description
10mm 10mm2 8mm2 copper solar dc pv heat energy system cables wire
Solar Cable Feature:1. Conductor: Class 5 tinned annealed stranded copper
2. Insulation:120°C XLPE/XLPO,black3. Jacket:120°C XLPE , black or red
4. Cores: Single Core or Twin Core
5. Voltage: 600/1000V,1000/1500V DC
6. Temperature Rating: -40ºC~90ºC(Max 120 ºC)Solar Cable Application:
Is Used In Photovoltaic Power Generation And Solar System,Interconnects Solar Modules And ElectricalComponents
In The Photovoltaic System,Suitable For Outdoor Extreme Environments,UV,Ozone,Hydrolysis Resistant.
Parameters for Solar PV Cable
|
Size
|
Cross Section
|
Conductor
Structure |
Outer
Diameter |
Max. DC Resistance
at 20ºC |
Rated Voltage
|
Rated
Current |
|
mm2
|
mm
|
mm
|
Ω/km
|
V
|
A
|
|
|
Single Core Solar Cable
|
||||||
|
1×2.5mm2
|
2.5mm2
|
49xΦ0.25
|
5.1
|
8.06
|
1000/1500
|
30
|
|
1×4.0mm2
|
4.0mm2
|
56xΦ0.285
|
6.1
|
4.97
|
1000/1500
|
50
|
|
1×6.0mm2
|
6.0mm2
|
78xΦ0.3
|
6.4
|
3.52
|
1000/1500
|
70
|
|
1x10mm2
|
10mm2
|
74xΦ0.4
|
7.3
|
2.12
|
1000/1500
|
95
|
|
1x16mm2
|
16mm2
|
224xΦ0.3
|
10.2
|
1.24
|
1000/1500
|
132
|
|
Dual-Core Solar Cable
|
||||||
|
2×2.5mm2
|
2.5mm2
|
49xΦ0.25
|
5.1×10.9
|
8.06
|
1000/1500
|
30
|
|
2×4.0mm2
|
4.0mm2
|
56xΦ0.285
|
6.1×12.3
|
4.97
|
1000/1500
|
50
|
|
2×6.0mm2
|
6.0mm2
|
78xΦ0.3
|
6.4×12.9
|
3.52
|
1000/1500
|
70
|
Henan Huadong Cable Co., Ltd. Is a Joint Stock Enterprise Integrated in Cable Production, And Domestic & International
Trade,Founded in 1999, Located in Xiuwu Industrial Zone, Jiaozuo and Occupied 150,000 Square Meters, With Advanced
20 Sets Equipments and 25 Sets Testing Machines, Annual Production Capacity Is over 15 Million Kilometers
We Mainly Produce and Export 1-35kv Power Cables, AAC,ACSR,AAAC Bare Conductors,Overhead Aerial Bundled ABC
Cables,Control Cables,Welding Cables, Rubber Cables, Mining Cables,Crane And Other Special Use Cables.
Nós somos China 10mm 10mm2 8mm2 Sistema de Energia Térmica Solar DC PV de Cobre Fios Cabo fabricação e fornecedor,Você pode obter mais detalhes com e-mail, você obterá preço barato ou preço de fábrica.
Get Latest Price Request a quote
Tags: Henan Huadong Cable Co., Ltd., Power Cable, Solar Cable
